- Size: 1
- Place of Origin: China
- Brand Name: MNAI
- Model Number: JHS
- Weight: 1.000 kg
Properties:
Waterproofing; oil resistance; cool resistance; abrasion resistance; flame resistance; anti-ultraviolet.
Structure:
Conductor: Fine strands of oxygen-free copper wire acc. to VDE 0295,class 6
Insulation: PE
Colour: <=0.5mm brown, black, blue, purple, pink, orange
>=0.5mm black number with white digital coding.
3cores or more with green/yellow earth wire
Sheath: Special TPE; b;ack(RAL9005) OR grey(RAL7001)
Standard: acc. to VDE 0482, part 265-2-2 resp.EN 50265-2-1 and IEC60332-1
Technical data:
Rated voltage: ≤ 0.5mm: 300/300V ≥ 0.5mm: 300/500V
Test voltage: 2500V
Minimum bending radius: 0.3m≤L≤0.6M
Burning vertically test: GB/T1 8380.1-2001, IEC60332-1:1993 test
Passedstandard: GB5023.6 , IEC60227-6, EN50214.
Temperature range: Fixed Installation: -30°C to +90°C
Flexing Installation: -5°C to +90°C
The minimum bending radius:Fixed 5*d
Moved: when travel <10m, bending radius of 7.5*d
when travel >=10m, bending radius of 10*d
